Product Specifications
| # Manufacturer Number | 1050690 |
| Diameter (Inch) | 5/64" |
| Shank (Inch) | 13/64"" |
| Flute Length (Inch) | 11/16" |
| Overall Length (Inch) | 1-11/16" |
| Drill Point Angle | 135 |
| Number of Flute | 2 |
| Material | HSS |
| Finish / Coating | Black Oxide |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Straight Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Inch):
5/64";Drill Bit Size (Decimal Inch)=0.0781""
Drill Bit Size (mm):
1.98mm
Drill Point Angle:
135 Degree
Flute Length (Inch):
11/16";Flute Length (Decimal Inch)=0.6875""
Flute Length (mm):
17.46mm
Overall Length (Inch):
1-11/16";Overall Length (Decimal Inch)=1.6875""
Overall Length (mm):
42.86mm
Material:
HSS
Finish/Coating:
Black Oxide
Flute Type:
Conventional Spiral
Cutting Direction:
Conventional Spiral
Shank Type:
Straight Shank
Coolant Through:
No
