Product Specifications
| # Manufacturer Number | 1486320 |
| Shank Size | 0.3810" |
| Overall Length | 3.9370" |
| Number of Flutes | 3 |
| Finish / Coating | SG |
| Material | Powdered Metal |
| Cutting Direction | Right |
| Flute Type | Normal Spiral Flute |
| Thread Length | 0.7400" |
| Size-Pitch | M10 x 1.5 |
| Limit | D6 |
| Tap Type | Bottoming |
| Helix Direction | Right Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Thread Limit:
D6
Number of Flutes:
3
Material:
Powdered Metal
Finish/Coating:
SG
Overall Length (Inch):
3-15/16"
Overall Length (Decimal Inch):
3.9370"
Overall Length (mm):
100.00mm
interval quantity:
1
