Product Specifications
| # Manufacturer Number | 1574475 |
| Diameter | 1.30mm |
| Shank Size | 3.00mm |
| Overall Length | 86.00mm |
| Flute Length | 36.00mm |
| Neck Length | 38.00mm |
| Drill Point Angle | 140 Degree |
| Shank Transition Angle | 15 Degree |
| Number of Flutes | 2 |
| Finish / Coating | Aqua EX Coated |
| Material | Solid Carbide |
| Coolant Thru | Yes |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Material:
Solid Carbide
Point Angle:
150 Degree
Number of Flutes:
2
Mill Diameter (Inch):
1/2"
Mill Diameter (Decimal Inch):
0.5000"
Mill Diameter (mm):
12.70mm
Overall Length (mm):
138.00mm
Finish/Coating:
Aqua EX
interval quantity:
1
