Product Specifications
| # Manufacturer Number | 64342 |
| Shank Size | 10.2330" |
| Overall Length | 6-3/8" |
| Number of Flutes | 4 |
| Material | HSSE-V |
| Cutting Direction | Right |
| Flute Type | Straight |
| Thread Length | 3" |
| Size-Pitch | 1-1/2-6 |
| Limit | H4 |
| Tap Type | Plug |
| Helix Direction | Right Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Thread Limit:
H4
Number of Flutes:
4
Overall Length (Inch):
6-3/8"
Overall Length (Decimal Inch):
6.3800"
Overall Length (mm):
161.93mm
Thread Length (Inch):
3"
Thread Length (Decimal inch):
76.20mm
Thread Length (mm):
4.00mm
Shank Diameter (Decimal inch):
10.2330"
Shank Diameter (mm):
259.92mm
Material:
HSSE-V
interval quantity:
1
