Premium High Performance Carbide End Mills for Pre-hardened & Hardened Steels
Features & Benefits:
- Ultra-fine micrograin carbide: The hardest most Wear resistant carbide possible for incredible Wear Resistance
- High Precision geometry: High accuracy all but eliminates need for benching and rework for mold makers
- High strength core diameter: Tools utilize thicker core diameters for the ultimate in strength and rigidity
- WXL coating - +1100 Celsius Oxidation Temp & +3100Hv in Hardness: Higher coating oxidation temp & Hardness dramatically improve Wear Resistance
Product Specifications
| Manufacturer Part Number | 36040311 |
| Cutting Diameter Tolerance (Decimal Inch) | +0 / -0.0008" |
| Cutting Direction | Right Hand |
| Diameter (Inch) | 3/32" |
| Diameter (Decimal Inch) | 0.094" |
| Helix Angle (Degree) | 30 Degree |
| Helix Direction | Right Hand |
| Length of Cut (Decimal Inch) | 0.375" |
| List Name | WXL-EMS |
| Number of Flutes | 4 |
| Overall Length (Decimal Inch) | 1.500" |
| Shank Diameter (Decimal Inch) | 0.125" |
| Shank Tolerance | h6 |
| Material | Carbide |
| Coating | WXL |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
OSG
Cutting Direction:
Right Hand
Diameter (Inch):
3/32"
Diameter (Decimal Inch):
0.0940"
Helix Angle:
30 Degree
Length of Cut (Decimal Inch):
0.3750"
Number of Flutes:
4
Overall Length (Decimal Inch):
1.5000"
Shank Diameter (Decimal Inch):
0.1250"
Material:
Carbide
Finish/Coating:
WXL
interval quantity:
1
