Features:
- Extreme accuracy-2 micron max. T.I.R.
- Highly polished and coated to prevent corrosion
- Can be used in standard ER collet chucks
Product Specifications
| Collet Series | ERos20 |
| Overall Diameter (mm) | 20mm |
| Body Width (mm) | 20mm |
| Capacity (mm) | 2-3mm |
| Min Capacity (mm) | 2mm |
| Max Capacity (mm) | 3mm |
| Overall Length (mm) | 31.5mm |
| Shank Size (mm) | 3mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Parlec
Collet Series:
ERos20
Size (Inch):
1/8"
Size (mm):
3mm
Size (Decimal Inch):
0.12"
