Features:
- Made-in-USA quality
- Extreme accuracy-Concentricy to 3 microns at 3X diameter
- Simplicity-no expensive setup machines required
- Balanced to 30,000 RPM @ G2.5
Product Specifications
| Taper | HSK50A |
| Collet Series | ER25 |
| Body Diameter (Inch) | 1.5" |
| Shank Size (Inch) | 1.97" |
| Shank Length (Inch) | 0.98" |
| Overall Length (Inch) | 3.73" |
| Projection (Inch) | 2.75" |
| Nose Diameter (Inch) | 1.57" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Parlec
Collet Series:
ER25
Shank Size (Decimal Inch):
1.9700"
Body Diameter (Decimal Inch):
1.5000"
Nose Diameter (Decimal Inch):
1.5700"
Shank Length (Decimal Inch):
0.9800"
Overall Length (Decimal Inch):
3.7300"
