Disc mill with positve/negative geometry which utilises 10 off SNHQ 1203.. double-sided inserts, cutting diameter 100 mm with 90 Degree approach angle and 27 mm connection bore according to DIN 8030-A, 50 mm protrusion length for deep slot milling with a width of cut of 6 mm.
Product Specifications
| EDP Number | 6758327 |
| Face Effective Cutting Edge Count | 5 |
| Peripheral Effective Cutting Edge Count | 10 |
| Insert Index Count | 10 |
| Cutting width (mm) | 6 mm |
| Max Cutting Depth (mm) | 23.5 mm |
| Axial Rake Angle | -0.5 |
| Radial Rake Angle | 2.5 |
| Max Rotational Speed | 7500 |
| Connection Bore Diameter (mm) | 27 mm |
| Hub Diameter (mm) | 48 mm |
| Cutting Diameter (mm) | 100 mm |
| Cutting Diameter (Inch) | 3.937" |
| Overall Length (mm) | |
| Overall Length (Inch) | |
| Number of Peripheral Edges in The Tool | 10 |
| Country of origin | Czech Republic |
