High feed cutter with positve/negative geometry which utilises 5 off ZDEW 1204.. single-sided inserts, cutting diameter 80 mm with 27 mm connection bore according to DIN 8030-A, 50 mm protrusion length, through coolant and differential pitch for face milling.
Product Specifications
| EDP Number | 6759670 |
| Peripheral Effective Cutting Edge Count | 5 |
| Cutting Pitch Differential | 1 |
| Insert Index Count | 5 |
| Coolant Supply Property | 1 |
| Axial Rake Angle | 10 |
| Radial Rake Angle | -6 |
| Max Rotational Speed | 11100 |
| Connection Diameter (mm) | 27 mm |
| Connection Diameter (Inch) | 1.063" |
| Keyway Width (mm) | 12 mm |
| Keyway Depth (mm) | 7 mm |
| Cutting Diameter (mm) | 62.5 mm |
| Max Cutting Diameter (mm) | 80 mm |
| Cutting Diameter (Inch) | 2.461" |
| Functional Length (mm) | 50 mm |
