Face mill with positve/negative geometry which utilises 4 off SEET 09T3AF.. or SEMT 09T3AF.. single-sided inserts, cutting diameter 32 to maximum 42.0 mm with 45 Degree approach angle and 16 mm connection bore according to DIN 8030-A, 40 mm protrusion length, through coolant and differential pitch for face milling and chamfering with a maximum depth of cut of 4.5 mm.
Product Specifications
| EDP Number | 6761701 |
| Peripheral Effective Cutting Edge Count | 4 |
| Cutting Pitch Differential | 1 |
| Insert Index Count | 4 |
| Coolant Supply Property | 1 |
| Axial Rake Angle | 20 |
| Radial Rake Angle | -5 |
| Max Rotational Speed | 19400 |
| Connection Diameter (mm) | 16 mm |
| Connection Diameter (Inch) | 0.63" |
| Counterbore Diameter Connection Bore (mm) | 14 mm |
| Keyway Width (mm) | 8.4 mm |
| Keyway Depth (mm) | 6.4 mm |
| Cutting Diameter (mm) | 32 mm |
| Max Cutting Diameter (mm) | 42 mm |
| Cutting Diameter (Inch) | 1.26" |
| Functional Length (mm) | 40 mm |
| Country of origin | Czech Republic |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Pramet
