| Manufacturer Part Number | FM-204-12-060 |
| Cutting Diameter (Decimal Inch) | 0.375" |
| Shank Diameter (Decimal Inch) | 0.375" |
| Maximum Cutting of Diameter (Decimal Inch) | 0.374" |
| Overall Length (Decimal Inch) | 4.000" |
| Flute Length (Decimal Inch) | 0.375" |
| Reach Length (Decimal Inch) | 1.563" |
| Neck Diameter (Decimal Inch) | 0.356" |
| Corner Radius (Decimal Inch) | 0.060" |
| Number of Flutes | 2 |
| Helix Angle (Degree) | 40 Degree |
| Cutting Direction | Right Hand |
| Helix Direction | Right Hand |
| Series | FM-204 |
| Coating | Uncoated |
| Product Type | Square End Mill |
