Product Specifications
| Manufacturer Part Number | MFM-202-20-BN |
| Cutting Diameter (mm) | 20.00mm |
| Shank Diameter (Imm) | 20.00mm |
| Maximum Cutting of Diameter (mm) | 0.76mm |
| Overall Length (mm) | 150.00mm |
| Flute Length (mm) | 21.00mm |
| Reach Length (mm) | 60.00mm |
| Neck Diameter (mm) | 19.00mm |
| Corner Radius (mm) | 10.00mm |
| Number of Flutes | 2 |
| Helix Angle (Degree) | 40 Degree |
| Cutting Direction | Right Hand |
| Helix Direction | Right Hand |
| Series | MFM-202 |
| Coating | Uncoated |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
RobbJack
Mill Diameter (Inch):
25/32"
Mill Diameter (Decimal Inch):
0.7900"
Mill Diameter (mm):
20.00mm
Number of Flutes:
2
Finish/Coating:
Uncoated
Shank Diameter (Inch):
25/32"
Shank Diameter (Decimal Inch):
0.7900"
Shank Diameter (mm):
20.00mm
Overall Length (Inch):
5-29/32"
Overall Length (Decimal Inch):
5.9100"
Overall Length (mm):
150.00mm
Cutting Direction:
Right Hand
interval quantity:
