RobbJack MSB-201-05-T | 5.00mm Diameter x 5.00mm Shank x 50.00mm OAL 2 Flute TiN Coated Ball End Mill

$39.74
Brand:
RobbJack
Mill Diameter (Inch):
13/64"
Mill Diameter (Decimal Inch):
0.2000"
Mill Diameter (mm):
5.00mm
Number of Flutes:
2
Overall Length (Inch):
1-31/32"
Overall Length (Decimal Inch):
1.9700"
Overall Length (mm):
50.00mm
Shank Diameter (Inch):
13/64"
Shank Diameter (Decimal Inch):
0.2000"
Shank Diameter (mm):
5.00mm
Finish/Coating:
TiN
Cutting Direction:
Right Hand
Helix Angle (Degree):
30 Degree
SKU:
25205341
Weight:
0.23 LBS
Shipping:
Calculated at Checkout
RobbJack MSB-201-05-T | 5.00mm Diameter x 5.00mm Shank x 50.00mm OAL 2 Flute TiN Coated Ball End Mill

Product Specifications
Manufacturer Part NumberMSB-201-05-T
Cutting Diameter (mm)5.00mm
Shank Diameter (mm)5.00mm
Maximum Cutting of Diameter (mm)0.20mm
Overall Length (mm)50.00mm
Flute Length (mm)8.00mm
Corner Radius (mm)2.50mm
Number of Flutes2
Helix Angle (Degree)30 Degree
Cutting DirectionRight Hand
Helix DirectionRight Hand
SeriesMSB-201
CoatingTiN
Product TypeBall End Mill
