RobbJack XG-502-10 | 0.313" Diameter x 0.313" Shank x 2.500" OAL 5 Flute AlTiN Coated Ball End Mill

$70.02
Brand:
RobbJack
Mill Diameter (Inch):
5/16"
Mill Diameter (Decimal Inch):
0.3130"
Mill Diameter (mm):
7.95mm
Number of Flutes:
5
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Overall Length (mm):
63.50mm
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3130"
Shank Diameter (mm):
7.95mm
Finish/Coating:
AlTiN
Cutting Direction:
Right Hand
SKU:
25208825
Weight:
0.23 LBS
Shipping:
Calculated at Checkout

Product Specifications
Manufacturer Part NumberXG-502-10
Cutting Diameter (Decimal Inch)0.313"
Shank Diameter (Decimal Inch)0.313"
Maximum Cutting of Diameter (Decimal Inch)0.312"
Overall Length (Decimal Inch)2.500"
Flute Length (Decimal Inch)0.813"
Corner Radius (Decimal Inch)0.020"
Number of Flutes5
Cutting DirectionRight Hand
Helix DirectionRight Hand
SeriesXG-502
CoatingAlTiN
Product TypeBall End Mill
