Product Specifications
| Manufacturer Part Number | 02712362 |
| Cutting Diameter (mm) | 4.50mm |
| Connection Diameter Machine Side (mm) | 6.00mm |
| Shank Diameter (mm) | 6.00mm |
| Chip Flute Length (mm) | 145.00mm |
| Functional Length Secondary (mm) | 149.00mm |
| Shank Length (mm) | 36.00mm |
| Usable Length (mm) | 135.00mm |
| Overall Length (mm) | 185.00mm |
| Corner Chamfer Width (mm) | 0.10mm |
| Tool Cutting Edge Angle (Degree) | 68 Degree |
| Corner Chamfer Angle (Degree) | 34 Degree |
| Flute Helix Angle (Degree) | 30 Degree |
| Flute Helix Hand | Right Hand |
| Coolant Entry Style Code | 4 |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 4 |
| Shank Type | Cylindrical |
| Material | Carbide |
| Product Type | Extra Long Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Material:
Carbide
Overall Length (Inch):
7-19/67"
Overall Length (Decimal Inch):
7.2835"
Overall Length (mm):
185.00mm
Flute Length (Inch):
5-17/4"
Flute Length (Decimal Inch):
5.7087"
Flute Length (mm):
145.00mm
Drill Point Angle:
136 Degree
Shank Type:
Cylindrical
interval quantity:
1
