Seco Tools 10139213 | T33-FSN01C06-14X2-65R M14 Thread Size x 14.00mm Diameter x 11.00mm Shank x 110.00mm OAL 6 Flute TiAIN+TiN Coated HSS-E-PM Thread Forming Tap

$231.00 $159.39
(You save $71.61)
Brand:
Seco Tools
Thread Size:
M14
Number of Flutes:
6
Finish/Coating:
TiAIN+TiN
Material:
HSS-E-PM
Thread Standard:
M
interval quantity:
1
SKU:
17994089
UPC:
Weight:
0.18 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10139213 | T33-FSN01C06-14X2-65R M14 Thread Size x 14.00mm Diameter x 11.00mm Shank x 110.00mm OAL 6 Flute TiAIN+TiN Coated HSS-E-PM Thread Forming Tap

Product Specifications
Manufacturer Part Number10139213
Thread Diameter (Decimal Inch)0.551"
Thread Diameter (mm)14.00mm
Threading Chamfer Length (Decimal Inch)0.188"
Threading Chamfer Length (mm)4.77mm
Tap Chamfer Length (Decimal Inch)0.188"
Tap Chamfer Length (mm)4.77mm
Connection Diameter Machine Side (Decimal Inch)0.433"
Connection Diameter Machine Side (mm)11.00mm
Shank Diameter (Decimal Inch)0.433"
Shank Diameter (mm)11.00mm
Functional Length (Decimal Inch)4.143"
Functional Length (mm)105.23mm
Usable Length (Decimal Inch)3.189"
Usable Length (mm)81.00mm
Overall Length (Decimal Inch)4.331"
Overall Length (mm)110.00mm
Thread Length (Decimal Inch)0.787"
Thread Length (mm)20.00mm
Thread Diameter SizeM14
Recommended Premachined Hole Diameter (Decimal Inch)0.516"
Recommended Premachined Hole Diameter (mm)13.10mm
Connection Size Code11.00X9.00
Connection Size Code Machine Side11.00X9.00
Maximum Premachined Hole Diameter (Decimal Inch)0.516"
Maximum Premachined Hole Diameter (mm)13.10mm
Minimum Thread Pitch (Decimal Inch)0.079"
Minimum Thread Pitch (mm)2.00mm
Maximum Thread Pitch (Decimal Inch)0.079"
Maximum Thread Pitch (mm)2.00mm
Number of Flute6
Shank TypeCylindrical
Thread Tolerance Class6HX
Threading Chamfer TypeC
Thread Form TypeM
Cutting DirectionRight Hand
Cutting Geometry TypeT33
Cutting Geometry Type TechnicalOil grooves
MaterialHSS-E-PM
CoatingTiAIN+TiN
Product TypeThread Forming Tap
