Product Specifications
| Manufacturer Part Number | 75054836 |
| Connection Diameter Machine Side (Decimal Inch) | 0.750" |
| Connection Diameter Machine Side (mm) | 19.05mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.260" |
| Contact Surface Diameter Machine Side (mm) | 32.00mm |
| Shank Diameter (Decimal Inch) | 0.750" |
| Shank Diameter (mm) | 19.05mm |
| Protruding Length (Decimal Inch) | 1.496" |
| Protruding Length (mm) | 38.00mm |
| Overall Length (Decimal Inch) | 1.969" |
| Overall Length (mm) | 50.00mm |
| Depth of Key Way (Decimal Inch) | 0.201" |
| Depth of Key Way (mm) | 5.10mm |
| Keyway Width (Decimal Inch) | 0.319" |
| Keyway Width (mm) | 8.10mm |
| Product Type | Slotting Cutter Adapter |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Shank Diameter (Decimal Inch):
0.7500"
Shank Diameter (mm):
19.05mm
Keyway Width (Decimal Inch):
0.3189"
Keyway Width (mm):
8.10mm
Overall Length (Decimal Inch):
1.9685"
Overall Length (mm):
50.00mm
interval quantity:
1
