Features
- Rugged and simple unit construction with a universally fitting design
- Sharp bezel serrations for positive grip
- Unbreakable crystal
- Hardened stainless steel stem
- No-glare satin finish on case
- Hardened stainless steel rack and spindle
- Massive bridge for rigid bearing support
- Hardened stainless steel gears and pinions
- Non-reflecting white eggshell finish on dial
- Jewel Bearings
Product Specifications
| Graduations (in) | .001" |
| Total Range (in) | .250" |
| Range One Rev. (in) | .100" |
| Dial Reading | 0-50-0 |
| Dial Color | White |
| Stem Diameter (in) | .375" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Type:
Dial Indicator
Maximum Measurement (Inch):
1/4"
Maximum Measurement (Decimal Inch):
0.2500"
Maximum Measurement (mm):
6.35mm
Dial Graduation (Inch):
0"
Dial Graduation (Decimal Inch):
0.0010"
Dial Graduation (mm):
0.025mm
Dial Reading:
0-50-0
Dial Diameter (Inch):
2-1/4"
Dial Diameter (Decimal Inch):
2.2500"
Dial Diameter (mm):
57mm
Dial Color:
White
Ships:
From Manufacturer
