Features
- Precision Ground Radius on each gage provides two-point contact for maximum accuracy
- Greater range
- Constant spring tension gives uniform contact pressure
- Both plungers are easily locked at any desired setting
- Handles can be individually ordered. Handles longer than 12" (300mm) are available on special order.
- Handles are rigidly attached to the contact plungers and are automatically self-centering
- Ends of both contacts are hardened and ground to a radius to allow proper clearance on the smallest hole the gage will enter
- Two telescoping contacts
Product Specifications
| Range (in) | 1/2 - 3/4" |
| Range (mm) | 13-19mm |
| Handle Length (in) | 2-3/8" |
| Handle Length (mm) | 60mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Minimum Measurement (Inch):
1/2"
Minimum Measurement (Decimal Inch):
0.5000"
Minimum Measurement (mm):
13mm
Maximum Measurement (Inch):
3/4"
Maximum Measurement (Decimal inch):
0.7500"
Maximum Measurement (mm):
19mm
Handle Style:
Rigid
Material:
Steel
Finish/Coating:
Satin Chrome
Ships:
From Manufacturer
