Features
- Tactile Measurement Button
- Two-Piece Construction with Bluetooth Low Energy Connectivity
- Diamond Stylus and Piezoelectric Pickup
- Li-Poly Battery
- Rubberized Molding
- Profile Graph
- Simple Navigation
Product Specifications
| Accuracy (in) | 5% of reading + 4 micro-in. |
| Accuracy (mm) | 5% of reading + 0.1 micron |
| Cutoff Lengths | 0.8mm |
| Filter | Gaussian |
| Measuring Range | 1600 micro-in. (40 microns) |
| Pick-up Stylus | Piezoelectric |
| Roughness Parameter | Ra,Rz,Rp,Rv,Rt,Rz1Max,Rsk,Rq,Rku,Pa,Pz,Pp,Pv,Pt |
| Tracer Tip | Diamond, 5 micron radius |
| Tracing Length | 0.2 in (5mm) |
| Tracing Speed | 0.08 in/sec (2mm/sec) |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Roughness Parameter Type:
Ra,Rz,Rp,Rv,Rt,Rz1Max,Rsk,Rq,Rku,Pa,Pz,Pp,Pv,Pt
Stylus Tip Radius (micro m):
5?m
Stylus Tip Radius (micro Inch):
200µin
Stylus Tip Radius (Inch):
0"
Stylus Tip Radius (Decimal Inch):
0.0002"
Stylus Tip Radius (mm):
0.01mm
Display Type:
LCD
Measuring Range (micro m):
200?m
For Use With:
SR160 Surface Roughness Tester
Ships:
From Manufacturer
