Features
- AD/B DIN Coolant-standard
- Factory Balanced to save spindle life, tool life and increase productivity
- Threaded through holes for a back-up screw (tool stop) or coolant through when removed
- TIR, 0.0002" at 4xdiameter
Product Specifications
| Manufacturer Part Number | 525408 |
| Collet System | ER |
| Collet Series | ER16 |
| Shank Type | Taper Shank |
| Taper Size | CAT40 |
| Projection (Decimal Inch) | 3.50" |
| Minimum Collet Capacity (Decimal Inch) | 0.019" |
| Maximum Collet Capacity (Decimal Inch) | 0.413" |
| Balanced to (RPM) | 20000 RPM at G2.5 |
| Collet Nut Diameter (Decimal Inch) | 1.26" |
| Seat Depth (Decimal Inch) | 0.87" |
| Product Type | Collet Chuck |
