Sumitomo 19W1772 | TPMT222EMU-AC8020P 0.2500" Circle Diameter x 3.40mm Hole Diameter x 0.0315" Radius Absotech Coated Carbide Turning Insert - All Industrial Tool Supply

Sumitomo 19W1772 | TPMT222EMU-AC8020P 0.2500" Circle Diameter x 3.40mm Hole Diameter x 0.0315" Radius Absotech Coated Carbide Turning Insert

$8.68 $7.81
(You save $0.87)
Total Price: $78.10

This product is sold in increments of 10

Ships:
From California in 1-2 Days
Brand:
Sumitomo
Insert Style:
TPMT
Insert Size:
222
Material:
Carbide
Length (Inch):
7/16"
Length (Decimal Inch):
0.4331"
Length (mm):
11.00mm
Inscribed Circle (Inch):
1/4"
Inscribed Circle (Decimal Inch):
0.2500"
Inscribed Circle (mm):
6.35mm
Thickness (Inch):
1/8"
Thickness (Decimal Inch):
0.1252"
Thickness (mm):
3.18mm
Corner Radius (Inch):
1/32"
Corner Radius (Decimal Inch):
0.0315"
Corner Radius (mm):
0.80mm
Manufacturer's Grade:
AC8020P
Ships:
From California in 1-2 Days
SKU:
23182375
Weight:
0.10 LBS
Shipping:
Free Shipping

Product Specifications
EDP Number19W1772
Product Code-ANSITPMT222EMU-AC8020P
Product Code-ISOTPMT110308N-MU
Manufacturer Grade IdentificationAC8020P
SeriesAC8000P
Cutting Edge Length (Decimal Inch)0.4331"
Cutting Edge Length (mm)11.00mm
Nose Radius (Decimal Inch)0.0315"
Nose Radius (mm)0.80mm
Inscribed Circle Diameter (Decimal Inch)0.2500"
Inscribed Circle Diameter (mm)6.35mm
Hole Diameter (mm)3.40mm
Insert Thickness (Decimal Inch)0.1252"
Insert Thickness (mm)3.18mm
Relief Angle11 Degree
Rake AnglePositive
Insert MaterialCarbide
Tolerance ClassM
Chip BreakerEMU
Corner Angle60
Insert StyleTPMT
Secondary Workpiece MaterialSteel
Primary Workpiece MaterialSteel
CoatingAbsotech
Coating ProcessCVD
Standard Designation of the Grade, Main ApplicationP20
Insert Holding MethodScrew-On
