Product Specifications
| EDP Number | 1PGZ006 |
| Product Code-ANSI | LNEX080404PNER-G-ACP100 |
| Manufacturer Grade Identification | ACP100 |
| Series | TSX |
| Maximum Depth of Cut (mm) | 8.00mm |
| Cutting Edge Length (Decimal Length) | 0.3386" |
| Cutting Edge Length (mm) | 8.60mm |
| Nose Radius (Decimal Inch) | 0.0157" |
| Nose Radius (mm) | 0.40mm |
| Insert Thickness (Decimal Inch) | 0.3169" |
| Insert Thickness (mm) | 8.05mm |
| Coating | ACP100 |
| Coating Process | CVD |
| Insert Style | LNEX |
| Insert Side | Double |
| Insert Size | 080404 |
| Chip Breaker | G |
| Tolerance Class | E |
| Insert Hand | R |
| Insert Material | Carbide |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Sumitomo
Insert Style:
LNEX
Insert Size:
080404
Material:
Carbide
Manufacturer's Grade:
ACP100
Coating:
ACP100
Width (Inch):
5/16"
Width (Decimal Inch):
0.3386"
Width (mm):
8.60mm
Thickness (Inch):
5/16"
Thickness (Decimal Inch):
0.3169"
Thickness (mm):
8.05mm
interval quantity:
10
Ships:
From California in 1-2 Days
