Product Specifications
| EDP Number | 5L00W05 |
| Product Code-Sumitomo | SMDH051L |
| Maximum Drill Depth (Decimal Inch) | 2.8346" |
| Maximum Drill Diameter (Decimal Inch) | 0.5311" |
| Minimum Drill Diameter (Decimal Inch) | 0.5118" |
| Shank Diameter (Decimal Inch) | 0.6250" |
| Shank Length (Decimal Inch) | 1.8740" |
| Overall Length (Decimal Inch) | 5.5945" |
| Series | SMD Replaceable Tip Drills |
| Hand | Right Hand |
| Coolant Through | Coolant Through |
| Shank Type | Flatted |
| Tool Material | Steel |
| Number of Tips | 1 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
Sumitomo
Series:
SMD Replaceable Tip Drills
Minimum Drill Diameter (Inch):
1/2"
Minimum Drill Diameter (Decimal Inch):
0.5118"
Minimum Drill Diameter (mm):
13.00mm
Maximum Drill Diameter (Inch):
17/32"
Maximum Drill Diameter (Decimal Inch):
0.5311"
Maximum Drill Diameter (mm):
13.49mm
Maximum Drill Depth (Inch):
2-27/32"
Maximum Drill Depth (Decimal Inch):
2.8346"
Maximum Drill Depth (mm):
72.00mm
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6250"
Shank Diameter (mm):
15.88mm
Through Coolant:
Coolant Through
interval quantity:
1
Ships:
From California in 1-2 Days
