Techniks 04806 | STRSHK Taper x 1" Diameter x 1" Shank x 40.00mm Projection Length ER20 Collet Chuck Extension

$262.00 $183.40
(You save $78.60)
Brand:
Techniks
Taper Size:
STRSHK
Collet Series:
ER20
Shank Size (Inch):
1"
Shank Size (Decimal Inch):
1.0000"
Body Diameter (Inch):
1"
Body Diameter (Decimal Inch):
1.0000"
Nose Diameter (mm):
28.00mm
Taper Length (mm):
50.00mm
interval quantity:
1
SKU:
55030119
UPC:
Weight:
0.55 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Features:

  • For coolant up to 1,500 PSI
  • Collet pocket T.I.R. 0.0001"
  • PowerCOAT coolant nut included

Product Specifications
Collet SeriesER20
Overall Diameter (Inch)1"
Shank Size (mm)20mm
Taper Length (mm)50mm
Overall Length (mm)90mm
Projection (mm)40mm
Nose Diameter (mm)28mm

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Techniks
Taper Size:
STRSHK
Collet Series:
ER20
Shank Size (Inch):
1"
Shank Size (Decimal Inch):
1.0000"
Body Diameter (Inch):
1"
Body Diameter (Decimal Inch):
1.0000"
Nose Diameter (mm):
28.00mm
Taper Length (mm):
50.00mm
interval quantity:
1
