Product Specifications
| Taper | HSK63A |
| Nose Diameter (mm) | 40mm |
| Body Diameter (mm) | 50mm |
| Overall Diameter (mm) | 48.01mm |
| Projection (mm) | 90mm |
| Nose Length (mm) | 47mm |
| Bore Depth (mm) | 42mm |
| Overall Length (mm) | 122mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
HSK63A
Body Diameter (mm):
50.00mm
Nose Diameter (mm):
40.00mm
Overall Length (mm):
122.00mm
Material:
Tool Steel
Overall Diameter (mm):
48.01mm
Bore Size (mm):
18.00mm
Bore Depth (mm):
42.00mm
interval quantity:
1
