Features:
- Rolled threads maintain material grain structure improving thread strength up to 20%
- Each MegaFORCE Retention knob is magnetic particle tested to ensure material integrity and physical soundness
- Tested at 2.5X the pulling forces of the drawbar
Product Specifications
| Taper Size | CAT40 |
| Degree | 45° |
| Head Diameter (Inch) | 0.74" |
| Neck Diameter (Inch) | 0.49" |
| Body Diameter (Inch) | 0.49" |
| Flange to Top Length (Inch) | 0.64" |
| Flange to Center of head Length (Inch) | 0.44" |
| Thread | 5/8-11 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
CAT40
Body Diameter (Decimal Inch):
0.4900"
Neck Diameter (Decimal Inch):
0.4900"
interval quantity:
