Features:
- Maximum T.I.R. only 0.0001"
- DualDRIVE for dual-contact spindles increases rigidity and accuracy
- CoolFLEX: through spindle and DIN-B coolant enabled
Product Specifications
| Taper | SBT40 |
| Taper Diameter (Inch) | 1.75" |
| Body Diameter (Inch) | 1.38" |
| Overall Diameter (Inch) | 2.48" |
| Bore Size (Inch) | 0.75" |
| Projection Length (Inch) | 4" |
| Nose Diameter (Inch) | 1.42" |
| Overall Length (Inch) | 6.57" |
| Nose Length (Inch) | 2.04" |
