Features:
- Balanced to 25,000 RPM at G2.5
- Maximum 0.0001" T.I.R. measured from taper to collet pocket
- PowerCOAT Nut increases holding power by 75%
Product Specifications
| Collet Series | ER40 |
| Overall Diameter (mm) | 48.01mm |
| Shank Size (mm) | 63mm |
| Taper Length (mm) | 32mm |
| Overall Length (Inch) | 40" |
| Projection (Inch) | 8" |
| Nose Diameter (Inch) | 2.48" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
HSK63A
Collet Series:
ER40
Shank Size (mm):
63.00mm
Body Diameter (mm):
48.01mm
Nose Diameter (Decimal Inch):
2.4800"
Taper Length (mm):
32.00mm
