Features:
- Balanced to 25,000 RPM at G2.5
- Maximum 0.0001" T.I.R. measured from taper to collet pocket
- PowerCOAT Nut increases holding power by 75%
Product Specifications
| Collet Series | ER20 |
| Overall Diameter (mm) | 30mm |
| Shank Size (mm) | 30mm |
| Taper Length (mm) | 33.4mm |
| Overall Length (mm) | 73.9mm |
| Projection (mm) | 40.5mm |
| Nose Diameter (mm) | 35mm |
| Thread | M25x1.5 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Techniks
Techniks 16000-2520 | ISO20 Taper x 30.00mm Shank x 40.50mm Length x 73.90mm OAL ER20 Collet Chuck
$263.00
$184.10
Techniks
Techniks 16000-2516 | ISO20 Taper x 30.00mm Shank x 41.40mm Length x 74.80mm OAL ER16 Collet Chuck
$263.00
$184.10
Brand:
Techniks
Taper Size:
ISO20
Collet Series:
ER20
Shank Size (mm):
30.00mm
Body Diameter (mm):
30.00mm
Nose Diameter (mm):
35.00mm
Taper Length (mm):
33.40mm
Shank Length (mm):
40.50mm
Overall Length (mm):
73.90mm
Overall Diameter (mm):
34.00mm
Shank Type:
ISO
Maximum RPM:
25 RPM
interval quantity:
1
