Features:
- 118 Degree split point jobber drills ideal for general purpose drilling (Diameters< 0.125" are not split)
- Solid Carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC19238 |
| Drill Diameter (Inch) | 0.1015" |
| Flute Length (Inch) | 1.2500" (1-1/4) |
| Shank Diameter (Inch) | 0.1015" |
| Overall Length (Inch) | 2.2500" (2-1/4) |
| Number of Flutes | 2 |
| Point Angle (Degree) | 118 Degree |
| Substrate | Carbide |
| Coating | Uncoated |
| Product Type | Jobber Length Drill Bit |
