Features:
- Optimized for relatively deep hole tapping in copper, brass, aluminum, and other soft ductile materials
- Slightly longer chamfer distributes cutting over greater number of teeth for increased production
- Can be used for plug or bottoming applications
- 52 Degree helix
- Taps are on blanks that meet ANSI specifications
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT76141 |
| Across Flat (Inch) | 0.2420" |
| Length of Cut (Inch) | 1.4375" (1-7/16) |
| End Length (Inch) | 0.4063" |
| Shank Diameter (Inch) | 0.3230" |
| Overall Length (Inch) | 3.1563" |
| Thread Size (Inch) | 7/16"-14 |
| Number of Flutes | 3 |
| Limit | H3 |
| Type | Semi Bottom |
| Substrate | High Speed Steel |
| Coating | Uncoated |
| Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Overall Length (Decimal Inch):
3.1563"
Overall Length (mm):
80.17mm
Number of Flutes:
3
Finish/Coating:
Uncoated
Material:
High Speed Steel
interval quantity:
1
