General Purpose Hand Taps is ready to ship the day of its purchase.
Features:
- High speed steel
- Engineered to tap left hand threads
- Taps are on blanks that meet ANSI specifications
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- TiN coating provides improved performance in a wide variety of materials, and generally used in applications with lower cutting speeds
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT82973 |
| Shank Diameter (Inch) | 0.5900" |
| Length of Cut (Inch) | 2.0000" (2) |
| Overall Length (Inch) | 4.2500" (4-1/4) |
| Thread Size (Inch) | 3/4"-16 |
| Across Flat (Inch) | 0.4420" |
| Number of Flutes | 4 |
| Limit | H3 |
| Coating | Uncoated |
| Substrate | High Speed Steel |
| Type | Bottom |
| Product Type | Straight Flute Tap |
