Features:
- Best used for blind hole tapping applications
- Semi-bottoming 45 Degree helix
- Optimized for steel, steel alloys, stainless steels, and a variety of other steels up to 32 Rc
- Taps are on blanks that meet ANSI specifications
- TiCN coating adds enhanced performance when AlTiN cannot be used
- High vanadium powdered metal
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT98852 |
| Shank Diameter | 0.1410" |
| Overall Length (Inch) | 2.0000" (2) |
| Length of Cut (Inch) | 0.3000" |
| Thread Size | M3.5 x 0.6 |
| End Length (Inch) | 0.1875" (3/16) |
| Type | Semi Bottom |
| Thread Limit | D4 |
| Number of Flutes | 3 |
| Coating | TICN |
| Substrate | High Vanadium Powdered Metal |
| Product Type | Spiral Flute Tap |
