"DrillMeister" TIDC L/D=5 indexable head drills.
Product Specifications
| Cutting Diameter Maximum (Inch) | 0.567" |
| Cutting Diameter Minimum (Inch) | 0.551" |
| Flange Diameter (Inch) | 0.787" |
| Connection Diameter Machine Side (Inch) | 0.748" |
| Overall Length (Inch) | 4.335" |
| Point Length (Inch) | 0.113" |
| Shank Length (Inch)) | 2.126" |
| Shank Length (mm) | 3.898" |
| Insert Seat Size Code (SSC) | 19 |
| Coolant Supply Property (CSP) | Through Hole |
| Application | General Drilling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.5670"
Minimum Cutting Diameter (Decimal Inch):
0.5510"
Flange Diameter (Decimal Inch):
0.7870"
Body Material:
Steel
Overall Length (Decimal Inch):
4.3350"
Point Length (Decimal Inch):
0.0830"
Shank Length (Decimal Inch):
1.8900"
Usable Length (Decimal Inch):
1.7540"
interval quantity:
1
