"DrillForceMeister" TIS L/D=5 indexable head drill.
Product Specifications
| Cutting Diameter Maximum (Inch) | 1.02" |
| Cutting Diameter Minimum (Inch) | 0.984" |
| Flange Diameter (Inch) | 1.654" |
| Connection Diameter Machine Side (mm) | 40 mm |
| Overall Length (Inch) | 6.870" |
| Point Length (mm) | 6.92 mm |
| Shank Length (mm) | 68 mm |
| Usable Length (mm) | 195.9 mm |
| Insert Seat Size Code (SSC) | 38 |
| Coolant Supply Property (CSP) | Through Hole |
| Application | General Drilling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
1.0200"
Minimum Cutting Diameter (Decimal Inch):
0.9840"
Flange Diameter (Decimal Inch):
1.6540"
Body Material:
Steel
Overall Length (Decimal Inch):
6.8700"
Point Length (Decimal Inch):
0.1500"
Shank Length (Decimal Inch):
2.3620"
Usable Length (Decimal Inch):
3.1320"
interval quantity:
1
