Screw-on boring bars, for position 80 degree rhombic insert with 11 degree clearance.
Product Specifications
| # MFG | 6850450 |
| Connection Diameter Machine Side (Inch) | 1/2" |
| Functional Length (Inch) | 5" |
| Functional Width (Inch) | 0.406" |
| Head Length (Inch) | 1" |
| Minimum Bore Diameter (Inch) | 0.687" |
| Shank Height (Inch) | 0.475" |
| Body Material | Steel |
| Application | For 80 Degree Rhombic Insert, For Miniature Machining |
| Tool Type | Internal Indexable-Turn Tool |
| Rake Angle Axial (Degree) | 5 Degree |
| Rake Angle Radial (Degree) | -2 Degree |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Minimum Bore Diameter (Decimal Inch):
0.6870"
Body Material:
Steel
Head Length (Inch):
1"
Head Length (Decimal Inch):
1.0000"
Shank Height (Decimal Inch):
0.4750"
interval quantity:
1
