Tungaloy 6950903 | CNMG 430.5 TSF T9225 1/2" Circle Diameter x 0.187" Thickness x 0.508" Edge Length x 0.008" Radius Ti-compound+Al2O3+TiN Coated Carbide Turning Insert

$20.30 $13.20
(You save $7.10)
Brand:
Tungaloy
Corner Radius (Decimal Inch):
0.0079"
interval quantity:
10
SKU:
23343525
UPC:
Weight:
1.23 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
Tungaloy 6950903 | CNMG 430.5 TSF T9225 1/2" Circle Diameter x 0.187" Thickness x 0.508" Edge Length x 0.008" Radius Ti-compound+Al2O3+TiN Coated Carbide Turning Insert

Product Specifications
Manufacturer Part Number6950903
Corner Radius (Decimal Inch)0.008"
Cutting Edge Length (Decimal Inch)0.508"
Maximum Depth of Cut (Decimal Inch)0.059"
Minimum Depth of Cut (Decimal Inch)0.008"
Inscribed Circle Diameter (Inch)1/2"
Insert Thickness (Decimal Inch)0.187"
Chip Breaker TypeNega-TSF
Fixing Hole Diameter (Deciaml Inch)0.203"
Cutting DirectionNeutral
GradeT9225
Applicable MaterialSteel, Stainless Steel, Cast Iron
Cutting Edge MaterialCarbide
Body MaterialCarbide
CoatingTi-compound+Al2O3+TiN
Product TypeTurning Insert
