Product Specifications
| Manufacturer Part Number | 1041JCN |
| Diameter (Inch) | 9/22" |
| Diameter (Decimal Inch) | 0.4094" |
| Diameter (mm) | 10.40mm |
| Shank Diameter (Inch) | 9/22" |
| Shank Diameter (Decimal Inch) | 0.4094" |
| Shank Diameter (mm) | 10.40mm |
| Flute Length (Inch) | 1-9/13" |
| Flute Length (Decimal Inch) | 1.6929" |
| Flute Length (mm) | 43.00mm |
| Overall Length (Inch) | 3-15/16" |
| Overall Length (Decimal Inch) | 3.9370" |
| Overall Length (mm) | 100.00mm |
| Point Length (Decimal Inch) | 0.1182" |
| Point Length (mm) | 3.00mm |
| Number of Flutes | 2 |
| Series | DJ543 |
| Point Angle | 120 Degree |
| Helix Angle | 38 Degree |
| Length/Diameter | Stub |
| Shank Tolerance | h7 |
| Coolant Through | No |
| Coating | TiN |
| Material | HSS EX |
| Hole Tolerance | h8 |
| Application | P,M |
| Cutting Direction | Right |
| Blank Standard | DIN6535-HA |
