Product Specifications
| EDP Number | 110104S |
| Shank Size (fractional) | 1/4" |
| Shank Size (Inch) | 0.2500" |
| Collapse Range (Inch) | 0.211-0.25" |
| Diameter (Inch) | 0.4530" |
| Diameter (mm) | 11.50mm |
| Overall Length (Inch) | 0.7090" |
| Overall Length (mm) | 18.00mm |
| Clamping Length (Inch) | 0.7090" |
| Clamping Length (mm) | 18.00mm |
| Style | Single Angle |
| Series | ER11S |
| Type | Sealed Precision Spring Collet |
