Product Specifications
| Manufacturer Part Number | 22002022 |
| Inscribed Circle (Decimal Inch) | 1.000" |
| Inscribed Circle (Inch) | 1" |
| Inscribed Circle (mm) | 25.40mm |
| Thickness (Decimal Inch) | 0.375" |
| Thickness (Inch) | 3/8" |
| Thickness (mm) | 9.52mm |
| Corner Radius (Decimal Inch) | 0.093" |
| Corner Radius (Inch) | 3/32" |
| Corner Radius (mm) | 2.40mm |
| Chipbreaker Application | Single Sided Heavy Roughing |
| Grade | YG3030 |
| Material | Carbide |
| Coating Process | CVD |
| Sqaure Size (Decimal Inch) | TiCN-Al2O3 |
| Cutting Edge Count | 2 |
| Shape | Rhombic 80° |
| Product Type | Turning Negative Insert |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Inscribed Circle (Decimal Inch):
1.0000";Inscribed Circle (Inch)=1""
Inscribed Circle (mm):
25.40mm
Thickness:
0.3750";Thickness (Inch)=3/8""
Thickness (mm):
9.53mm
Corner Radius (Inch):
3/32";Corner Radius (Decimal Inch)=0.0930""
Corner Radius (mm):
2.40mm
Grade:
YG3030
Material:
Carbide
Coating:
TiCN-Al2O3
