Product Specifications
| Manufacturer Part Number | AR024C |
| Bore Diameter (Inch) | 3/8" |
| Bore Diameter (Decimal Inch) | 0.3750" |
| Bore Diameter (mm) | 9.53mm |
| Gage-Length (Inch) | 3-3/20" |
| Gage Length (Decimal Inch) | 3.1500" |
| Gage Length (mm) | 80.01mm |
| Functional Length (Inch) | 1-5/12" |
| Functional Length (Decimal Inch) | 1.4170" |
| Functional Length (mm) | 35.99mm |
| Set Screw End Mill (Decimal Inch) | 0.6300" |
| Screw | UNF3/8-24 5/16L |
| Set of Screw | 1 |
| Taper Accuracy | N/A |
| RPM | 25000 RPM |
| Coolant System | AD+C |
| Product Type | End Mill Holder |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
