Product Specifications
| Manufacturer Part Number | DGE433044 |
| Diameter (Inch) | 13/75" |
| Diameter (Decimal Inch) | 0.1732" |
| Diameter (mm) | 4.40mm |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (mm) | 6.00mm |
| Flute Length (Inch) | 1-5/12" |
| Flute Length (Decimal Inch) | 1.4173" |
| Flute Length (mm) | 36.00mm |
| Overall Length (Inch) | 2-21/23" |
| Overall Length (Decimal Inch) | 2.9134" |
| Overall Length (mm) | 74.00mm |
| Point Length (Decimal Inch) | 0.0520" |
| Point Length (mm) | 1.32mm |
| Number of Flute | 2 |
| Cutting Direction | Right Hand |
| Point Angle (Degree) | 118 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Blank Standard | DIN6537 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | DLC |
| Product Type | Coolant Fed Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Shank Diameter (Inch):
13/55"
Shank Diameter (Decimal Inch):
0.2362"
Shank Diameter (mm):
6.00mm
Flute Length (Inch):
1-5/12"
Flute Length (Decimal Inch):
1.4173"
Flute Length (mm):
36.00mm
Overall Length (Inch):
2-21/23"
Overall Length (Decimal Inch):
2.9134"
Overall Length (mm):
74.00mm
Drill Point Angle:
118 Degree
Finish/Coating:
DLC
Material:
Carbide
