Product Specifications
| Manufacturer Part Number | E5I03250 |
| Mill Diameter (Inch) | 62/63" |
| Mill Diameter (Decimal Inch) | 0.9843" |
| Mill Diameter (mm) | 25.00mm |
| Shank Diameter (Inch) | 62/63" |
| Shank Diameter (Decimal Inch) | 0.9843" |
| Shank Diameter (mm) | 25.00mm |
| Length of Cut (Inch) | 1-1/2" |
| Length of Cut (Decimal Inch) | 1.4961" |
| Length of Cut (mm) | 38.00mm |
| Overall Length (Inch) | 4-1/64" |
| Overall Length (Decimal Inch) | 4.0157" |
| Overall Length (mm) | 102.00mm |
| Ball Nose (Decimal Inch) | 0.3937" |
| Ball Nose (Inch) | 50/127" |
| Ball Nose (mm) | 10.00mm |
| Helix | 30 Degree |
| Series | E5I03 |
| Coated | Bright |
| Material | Carbide |
| Type | Ball Nose Single End |
| Corner Type | Ball Nose |
