Product Specifications
Manufacturer Part Number | E5I58032 |
Diameter (Inch) | 1/2" |
Diameter (Decimal Inch) | 0.5000" |
Diameter (mm) | 12.70mm |
Shank Diameter (Inch) | 1/2" |
Shank Diameter (Decimal Inch) | 0.5000" |
Shank Diameter (mm) | 12.70mm |
Length of Cut (Inch) | 5/8" |
Length of Cut (Decimal Inch) | 0.6250" |
Length of Cut (mm) | 15.88mm |
Overall Length (Inch) | 2-1/2" |
Overall Length (Decimal Inch) | 2.5000" |
Overall Length (mm) | 63.50mm |
Ball Nose Radius (Inch) | 1/4" |
Ball Nose Radius (Decimal Inch) | 0.2500" |
Ball Nose Radius (mm) | 6.35mm |
Number of Flutes | 3 |
Series | E5I58 |
Helix Angle | 37 Degree |
Shank Style | Plain |
Coating | Bright |
Material | Carbide |
Cut Type | Center |
Corner Type | Ball Nose |
Type | Ball Nose |
Cutting Direction | Right |
Application | N |
![](https://cdn11.bigcommerce.com/s-mzpq4daxph/product_images/uploaded_images/warning-icon-new.png)
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
1/2"
Mill Diameter (Decimal Inch):
0.5000"
Mill Diameter (mm):
12.70mm
Number of Flutes:
3
Length of Cut (Inch):
5/8"
Length of Cut (Decimal Inch):
0.6250"
Length of Cut (mm):
15.88mm
Material:
Carbide
Shank Type:
Plain
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Overall Length (mm):
63.50mm
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Finish/Coating:
Bright
Cutting Direction:
Right
Helix Angle:
37 Degree
Application:
N
