Product Specifications
| EDP Number | EM897080 |
| Diameter (Decimal Inch) | 0.3100" |
| Diameter (Inch) | 23/73" |
| Diameter (mm) | 8.00mm |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (mm) | 8.00mm |
| Length of Cut (Decimal Inch) | 0.3150" |
| Length of Cut (Inch) | 23/73" |
| Length of Cut (mm) | 8.00mm |
| Length Below Shank (Decimal Inch) | 0.9449" |
| Length Below Shank (Inch) | 17/18" |
| Length Below Shank (mm) | 24.00mm |
| Overall Length (Decimal Inch) | 2.3622" |
| Overall Length (mm) | 60.00mm |
| Corner Radius (Decimal Inch) | 0.0197" |
| Corner Radius (Inch) | 1/51" |
| Corner Radius (mm) | 0.50mm |
| Overall Length (Inch) | 2-25/69" |
| Neck Diameter (Decimal Inch) | 0.3012" |
| Neck Diameter (Inch) | 25/83" |
| Neck Diameter (mm) | 7.65mm |
| Number of Flutes | 6 |
| Series | EM897 |
| Helix Angle (Degree) | 45 Degree |
| Shank Style | Plain |
| Coating | ALTiN |
| Cut Type | Center Cut |
| Length Type | Stub Length |
| Material | Carbide |
| Cutting Direction | Right |
| Application | P |
| Produce Type | Corner Radius End Mill |
