Product Specifications
| Manufacturer Part Number | EMD49048 |
| Diameter (Inch) | 3/4" |
| Diameter (Decimal Inch) | 0.7500" |
| Diameter (mm) | 19.05mm |
| Shank Diameter (Inch) | 3/4" |
| Shank Diameter (Decimal Inch) | 0.7500" |
| Shank Diameter (mm) | 19.05mm |
| Length of Cut (Inch) | 1-1/2" |
| Length of Cut (Decimal Inch) | 1.5000" |
| Length of Cut (mm) | 38.10mm |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.0000" |
| Overall Length (mm) | 101.60mm |
| Corner Radius (Inch) | 2/57" |
| Corner Radius (Decimal Inch) | 0.0350" |
| Corner Radius (mm) | 0.89mm |
| Number of Flutes | 4 |
| Series | EMD49 |
| Shank Style | Flat |
| Helix Angle | Multiple |
| Coating | AlTiN |
| Material | Carbide |
| Cut Type | Center |
| Type | High Performance |
| Application | P,M,K |
| Cutting Direction | Right |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Application:
P,M,K
interval quantity:
1
