Product Specifications
| Manufacturer Part Number | G9H99014N |
| Mill Diameter (Inch) | 7/32" |
| Mill Diameter (Decimal Inch) | 0.2188" |
| Mill Diameter (mm) | 5.56mm |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Shank Diameter (mm) | 6.35mm |
| Length of Cut (Inch) | 7/16" |
| Length of Cut (Decimal Inch) | 0.4375" |
| Length of Cut (mm) | 11.11mm |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (mm) | 50.80mm |
| Ball Nose (Decimal Inch) | 0.1094" |
| Ball Nose (Inch) | 7/64" |
| Ball Nose (mm) | 2.78mm |
| Helix | 30 Degree |
| Series | G9H99 |
| Coated | X-Coating |
| Material | Carbide |
| Type | Ball Nose Single End |
| Corner Type | Ball Nose |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Decimal Inch):
0.2188"
Mill Diameter (Inch):
7/32"
Mill Diameter (mm):
5.56mm
Shank Diameter (Decimal Inch):
0.2500"
Shank Diameter (Inch):
1/4"
Shank Diameter (mm):
6.35mm
Length of Cut (Decimal Inch):
0.4375"
Length of Cut (Inch):
7/16"
Length of Cut (mm):
11.11mm
Overall Length (Decimal Inch):
2.0000"
Overall Length (Inch):
2"
Overall Length (mm):
50.80mm
Finish/Coating:
X-Coated
Material:
Carbide
Helix Angle:
30 Degree
Number of Flutes:
4
Shank Style:
Plain
interval quantity:
1
