YG1 GM876040 | 2 Flute Carbide Ball Nose End Mill

$48.95 $33.04
(You save $15.91)
Brand:
YG1
Number of Flutes:
2
Length of Cut (Decimal Inch):
0.1969"
Length of Cut (mm):
5.00mm
Material:
Carbide
Overall Length (Inch):
2-1/8"
Overall Length (Decimal Inch):
2.1260"
Overall Length (mm):
54.00mm
interval quantity:
1
SKU:
25176175
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
YG1 GM876040 | 2 Flute Carbide Ball Nose End Mill

Product Specifications
Manufacturer Part NumberGM876040
Mill Diameter (Inch)3/19"
Mill Diameter (Decimal Inch)0.1575"
Mill Diameter (mm)4.00mm
Shank Diameter (Inch)13/55"
Shank Diameter (Decimal Inch)0.2362"
Shank Diameter (mm)6.00mm
Length of Cut (Inch)12/61"
Length of Cut (Decimal Inch)0.1969"
Length of Cut (mm)5.00mm
Overall Length (Inch)2-1/8"
Overall Length (Decimal Inch)2.1260"
Overall Length (mm)54.00mm
Ball nose Radius (Inch)3/38"
Ball Nose Radius (Decimal Inch)0.0787"
Ball Nose Radius (mm)2.00mm
Helix (Degree)30 Degree
Number of Flute2
Shank TypePlain
MaterialCarbide
Product TypeBall Nose End Mill
