Product Specifications
| EDP Number | SEM846010026S |
| Diameter (Decimal Inch) | 0.0394" |
| Diameter (Inch) | 3/76" |
| Diameter (mm) | 1.00mm |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Decimal Inch) | 0.0394" |
| Length of Cut (Inch) | 3/76" |
| Length of Cut (mm) | 1.00mm |
| Overall Length (Decimal Inch) | 1.9685" |
| Overall Length (Inch) | 1-31/32" |
| Overall Length (mm) | 50.00mm |
| Ball Nose Radius (Decimal Inch) | 0.0197" |
| Ball Nose Radius (Inch) | 1/51" |
| Ball Nose Radius (mm) | 0.50mm |
| Shank Style | Plain |
| Helix Angle (Degree) | 30 Degree |
| Coating | AlCrN |
| Number of Flutes | 2 |
| Cut Type | Center Cut |
| Corner Type | Ball Nose |
| Length Type | Long Neck |
| Series | SEM846 |
| Material | Carbide |
| Product Type | Ball Nose End Mill |
